Steps to Jekyll hosting on S3 and CloudFront with SSL with Forestry.io Deployment

August 25, 2018

Here are the steps I went through to get a new / fresh blog up using Jekyll and deployed to Amazon S3 using Forestry.io with CloudFront and SSL.

Creating the Jekyll site

It's probably best to follow the Jekyll quick start quide, but here's basically what I went through...

  • Create a GitHub repo (or something similar)
  • Clone the new repo to your local machine and create the new Jekyll site framework. You should follow the above quick start guide, but these are the things I did on my OS X machine (that is already well setup for software development)...
git clone https://github.com/<GITHUB USER>/<GITHUB REPO NAME>.git
cd <GITHUB REPO NAME>
rvm use 2.5.1
gem install jekyll bundler
jekyll new . --force
bundle install
jekyll serve
  • A new Jekyll site should now be available on http://localhost.com:4000
  • do the following to push the fresh Jekyll site to GitHub
git commit -am 'adding in the jekyll site'
git push

Where the files will live

The site files will live in an Amazon Simple Storage Service bucket. This bucket will then be attached to Amazon CloudFront so that it can support SSL (as well as have global content distribution).

  1. Create a S3 bucket:
    • use the bucket name static.YOUR-DOMAIN.com - this will be where the non-CloudFront-ed content will live.
  2. Setup Static Web Hosting on the new bucket
    • index.html as index document
    • error.html as error document
  3. Set the bucket permissions under Permssions > Bucket Polciy add this:
{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Sid": "PublicReadGetObject",
      "Effect": "Allow",
      "Principal": "*",
      "Action": "s3:GetObject",
      "Resource": "arn:aws:s3:::static.YOUR-DOMAIN.com/*"
    }
  ]
}

Create an IAM user for S3 access

  • In the AWS management console, go to IAM and add a user.
  • Name the user and give the user Progmatic Acces
  • Use the Attach existing policies link and add AmazonS3FullAccess
  • Save the CSV file that this will generate somewhere safe. The values will be needed in the deployment phase.

Setting up the domain

In Route 53 click Create Record Set and create an A - IPv4 address with a name of static and that is an alias to the static.YOUR-DOMAIN.com S3 bucket.

EASY: Using forestry.io to deploy

An easy way to now deploy the site is using forestry.io which is a tool to edit Jekyll (and Hugo) sites online. Behind the scenes you are just editing and commiting the post files to GitHub.

  1. Import the GitHub repo to forestry.io
  2. Under the Settings side menu, click on Deployment and select Amazon S3 filling in the correct bucket name (static.YOUR-DOMAIN.com) and the Access Key and Secret from the IAM CSV
  3. If all goes swimmingly, you should be able to make an edit using the forestry.io online editor and the site should get deployed to your S3 bucket. Which should be available at the domain name http://static.YOUR-DOMAIN.com

Create a SSL certificate

In Amazon Certificate Manager create an SSL certificate for your domains

  • Select Request a public certificate
  • Add your domain names:
    • YOUR-DOMAIN.com and
    • www.YOUR-DOMAIN.com
  • Set Default Root Object to index.html
  • DNS validating is easy if you use Route53 for DNS - Amazon will make the the changes to Route53 for you

This will take some time, so wait until it completes before moving on to the CloudFront step.

Setup CloudFront

Once the SSL certificate is issued you can create a new Amazon CloudFront distribution.

  • Select Web
  • use the static address of the S3 bucket for the Prigin Domain Name - IE http://static.YOUR-DOMAIN.com.s3-website-us-east-1.amazonaws.com as seen in this StackOverflow answer: https://stackoverflow.com/a/33087418/2642232 NOTE
  • I selected Redirect HTTP to HTTPS
  • Add your Alternate Domain Names (CNAMES) which should be:
    • YOUR-DOMAIN.com
    • www.YOUR-DOMAIN.com
  • Select Custom SSL Certificate and select your certificate from the dropdown menu

This should be all the settings you need to set. Click Create Distribution and wait until it deploys. This will also take some time.

Once deployed to CloudFront, you should be able to get the CloudFront Domain Name from your Distributions which will look something like xhja1sdfs7df.cloudfront.net. Copy this address for the next step

NOTE: Entering the static website value here should allow `permalink: pretty` in your config - so that you don't need `index.html` at the end of links...

Update your DNS

In Route53

  • add a CNAME record for the www.YOUR-DOMAIN.com entry with the CloudFront value from above (i.e. xhja1sdfs7df.cloudfront.net)
  • add an A - IPv4 address record with the alias of the CloudFront dropdown value.

Next Steps

The deployment currently is getting handled by forestry.io which is all well and good, but better would be a deployment on check-in to GitHub - Forestry may be actually doing this, but a tool more focused on deployment such as CodeShip seems like a better idea. I may pursue this in the near (or distant) future.
